Designed on the concepts of outstanding performance, superior drive control and user centric programming, Mitsubishi's F Series has been reborn as the MELSEC iQ-F Series.

Mitsubishi MELSEC iQ-F

From stand alone use to networked system applications, MELSEC iQ-F Series brings your business to the next level of industry, offering enhanced high speed bus, expanded built-in functions, advanced SSCNETIII/H support and improved engineering environment. Program and parameters are set with the GXWorks3 engineering software.

The FX5U gives the FX a performance boost and adds features that set benchmark standards for compact PLCs. It enables users to develop more complex and sophisticated automation systems, as well as higher performance applications, without having to migrate to a larger and more costly PLC family.

Connectivity

The FX5U offers simple connection options to a wide range of automation equipment, including Mitsubishi Electric servos and inverters, Cognex vision systems, networks and energy meters, with reduced wiring effort and no additional programming.

Positioning Control

The FX5U includes Mitsubishi Electric's Simple Motion Unit as an intelligent function module, providing the ability to perform sophisticated motion control for up to 4 axes. Functions include linear interpolation, circular interpolation, positioning control, synchronized control, encoder following and electronic cam.

The new Mitsubishi iQ-R series CPU offers dramatic improvements in performance, setting new benchmark standards for processing speed. This not only enables users to realize enhanced system designs, but also provides the basis for significant reduction in hardware costs. At the same time, the iQ-R series offers reductions in development cost, maintenance cost and risk of system failure, while providing an innovative upgrade path that will enable users to take advantage of ongoing developments through software upgrades rather than hardware upgrades.

Internal Database

The CPU includes an internal database that can be installed into the SD memory card. This allows a selection of database commands that can add/ delete/change records to be utilized for simple recipe functions. It is also easy to import/export Unicode files for use in spreadsheets. This is useful where multiple product variations are produced using the same machine process.

High Speed and Synchronization

The iQ-R boasts a high speed system bus for synchronized data communications between multiple CPUs. This improves performance and accuracy, especially for high speed motion control applications.

Enhanced Security Features

iQ-R has a variety of security features to protect intellectual property and plant safety. Engineers can restrict access at the network level using IP filtering, lowering the risk of hacking or any other unauthorized third party access. At the controller level, security key authentication prevents unauthorized access to the program or execution of the CPU.

Highly reliable control easily realized at low cost

Mitsubishi Electric Automation, Inc. has paired its proven iQ-R Series integrated control platform with at redundant function module to create a redundant process control system for applications that require highly reliable control. The iQ-R Series Process CPU/Redundant System is designed specifically for industries such as oil and gas, wastewater and building automation with applications that require near 100 percent uptime to prevent harmful or costly disruptions.

• Redundancy across multiple levels, reducing single-point failures
• High availability at multiple levels for improved system reliability
• Extensive visualization and data acquisition with Mitsubishi Electric SCADA MC Works64
• Easy configuration with GX Works3 integrated engineering software
• Mitsubishi MELSEC automation controller

This high-performing process control solution is also ideal for industries such as chemical or food and beverage that require very precise ingredient mixing and recipe management. Because their numerous production stages require tight synchronization, a disruption in one stage may lead to bottlenecks in others.

The iQ-R Series integrated design allows machines or production lines to consolidate control in one rack. The system can have up to 4 CPU's per rack for any combination of motion, sequence or process control.

The GOT2000 inherits all the features of the popular GOT1000 series, and introduces a more refined and advanced function set. The GOT2000 boasts advanced functionality, acts as a seamless gateway to other industrial automation devices, all while increasing productivity and efficiency. The high quality display is designed to optimize operator control and monitoring of device and line statuses. If you are looking for an intuitive operation terminal, the new tablet-like operability and the higher functionality of operator terminals makes the GOT2000 the ideal choice.

This new generation of operator interface products offers advanced features such as an intuitive gesture touch interface and a multitude of communications options including a wireless LAN interface. Other features include an SD card interface, expansion slots for optional communication, dual processors and multi-touch control.

The new range of GS HMIs from Mitsubishi Electric are a cost-effective series offering a simple and flexible entry-level option for newcomers to the world of machine visualization. Besides all the standard basic functions, it also includes additional ones such as data logging, FA transparent mode and operator authentication.

Mitsubishi GOT simple HMI

The FA transparent function allows access to automation components such as PLCs, frequency inverters and servo amplifiers within a system via the HMI. This enables data from connected components to be viewed and parameters or other settings to be adjusted from a central location. These 7" and 10" panels share a common specification apart from the size of the display.

• 9MB of user memory WVGA 800 x 480 display with LED backlight
• Built-in Ethernet port, RS422, RS-232 ports and USB device port
• Built-in SD card slot
• Vertical display capability
• Operator name and password protection

Even when a control system is specified by the end user, the chosice of servo drives is frequently left to the OEM. Now we can offer state-of-the-art servo performance.

Mitsubishi Electric introduces state-of-the-art servo performance with Advanced Vibration Suppression Control?, One-Touch Auto-Tuning?, and incredible reliability with an EtherCAT? interface for use with custom PC based control systems or competitor's EtherCAT motion systems. The MR-J4-TM Multi-Network Servo Drive with EtherCAT combines the industry-leading performance, features, and reliability of the MR-J4 Series servo system with an EtherCAT interface for customers where custom PC based control systems or competitor's EtherCAT controllers are specified.

The MR-J3 has raised the bar for servo speed and performance with a capacity range of 50W to 55kW, we reduced the size of both the amplifier and motor, added a high resolution encoder and advanced auto-tuning and vibration control. With even higher positioning accuracy and responsiveness, the MR-E Super is an excellent choice for applications ranging from 100W to 2kW. The MR-J2-JR supports the following control methods: Position, Speed, Torque, SSCNET Network, Built-In Motion, and RS-485 Multi Drop.

FR-D700 is Mitsubishi Electric’s class-leading range of micro drives. You can rely on this innovative solution for optimized performance and reliability on the job. Suitable for a wide variety of general purpose motor speed control applications, the FR-D700 was built from the ground up using custom components and has earned an enviable reputation for durability and dependability in adverse environments. This highly compact design offers a reduced installation footprint and a 5 Year Warranty.

The FR-A800 Series delivers performance, control and accuracy with the latest in AC motor control technology and Mitsubishi electric automation. The FR-A800 series offers a host of embedded functions and algorithms that enable seamless control of both traditional AC induction and permanent magnet motors. Using Real sensorless vector (RSV), magnetic flux vector and vector control users can quickly optimize motor performance based on any requirement. Harness this robust technological solution to streamline AC motor control management.

Available in models up to 10HP, the FR-E800 Series, with safety functionality meeting IEC 61508 standards, supports various networks such as CC-Link IE TSN, a next-generation open industrial network, and make manufacturing smarter in various fields by integrating the world's first corrosive gas environment detection circuit and the industry's first AI-based diagnostic functions. Leverage these state-of-the-art capabilities to operate compliantly and efficiently thanks to intuitive functions that support your manufacturing requirements.

The FR-F800 Series is a pump and fan control VFD optimized for maximum energy saving. Equally at home in an industrial environment or as part of an integrated HVAC system, FR-F800 can also be used as a cost-effective drive for controlling other types of lighter-duty constant torque loads. Optimum excitation control ensures that the energy-saving effects are realized during constant torque as well as during the motor’s acceleration/deceleration operations. These versatile capabilities maximize performance for your needs.
